| Artikelnummer | LH350H01-FD01-A41 |
| Marke | LG Display |
| Größe | 3.5 |
| Anwendung | MPH |
| Auflösung | 320×480 |
| Komposition | LCM |
| Helligkeit | 450 |
| CR | 200:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | MIPI |
| Panel-Marke | LG Display |
| Panel-Modell | LH350H01-FD01-A41 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 3.5 inch |
| Auflösung | 320(RGB)×480 , HVGA |
| Anzeigemodus | TN, Normally White, Transflective |
| aktiver Bereich | 49.92×74.88 mm |
| Umriss | 55.14×82.84×2.25 mm |
| Oberfläche | |
| Helligkeit | 450 cd/m² (Typ.) |
| Kontrastverhältnis | 200:1 (Typ.)(Transmissive) |
| Farben anzeigen | 16.7M (8-bit) |
| Reaktionszeit | 6/20 (Typ.)(Tr/Td); 40 (Typ.)(G to G) |
| Blickwinkel | 60/60/60/57 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 6S1PWLEDWithout Driver |
| Signalschnittstelle | MIPI (2 data lanes), 20 pins |
| Eingangsspannung | 3.0/5.672/1.8V (Typ.)(VDDC/VDDA/LOVCC) |
| Anwendung | MPH |
