| Artikelnummer | DLC0220KZG |
| Marke | Other |
| Größe | 2.2 |
| Anwendung | MPH |
| Auflösung | 320×320 |
| Komposition | LCM |
| Helligkeit | 200 |
| CR | 120:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | TTL |
| Panel-Marke | DLC |
| Panel-Modell | DLC0220KZG |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 2.2 inch |
| Auflösung | 320(RGB)×320 |
| Anzeigemodus | ECB, Normally White, Transflective |
| aktiver Bereich | 39.36×39.36 mm |
| Umriss | 47.4×51.85×2.7 mm |
| Oberfläche | |
| Helligkeit | 200 cd/m² (Typ.) |
| Kontrastverhältnis | 120:1 (Typ.)(Transmissive)5:1 (Typ.)(Reflective) |
| Farben anzeigen | 262K (6-bit), CIE193145% |
| Reaktionszeit | 35 (Typ.)(Tr+Td) |
| Blickwinkel | 45/45/40/50 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 3S1PWLEDWithout Driver |
| Signalschnittstelle | Parallel RGB (1 ch, 6-bit), 39 pins |
| Eingangsspannung | 3.0V (Typ.)(VDD) |
| Anwendung | MPH |
