| Artikelnummer | DLC0283FZG-7 |
| Marke | Other |
| Größe | 2.8 |
| Anwendung | MPH |
| Auflösung | 240×320 |
| Komposition | LCM |
| Helligkeit | 300 |
| CR | 400:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | CPU/RGB |
| Panel-Marke | DLC |
| Panel-Modell | DLC0283FZG-7 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 2.8 inch |
| Auflösung | 240(RGB)×320 , QVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 43.2×57.6 mm |
| Umriss | 50×70 mm |
| Oberfläche | |
| Helligkeit | 300 cd/m² (Typ.) |
| Kontrastverhältnis | 400:1 (Typ.) |
| Farben anzeigen | 262K , CIE193150% |
| Reaktionszeit | 25 (Typ.)(Tr+Td) |
| Blickwinkel | 60/60/60/45 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 5S1PWLEDWithout Driver |
| Signalschnittstelle | CPU/RGB, 39 pins |
| Eingangsspannung | 1.8/2.8V (Typ.)(IOVCC/VCC) |
| Anwendung | MPH |
