| Artikelnummer | AMEJ006 |
| Marke | Samsung |
| Größe | 2.8 |
| Anwendung | MPH |
| Auflösung | 240×400 |
| Komposition | OLED |
| Helligkeit | 200 |
| CR | 2000:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | self |
| Schnittstelle | CPU |
| Panel-Marke | SAMSUNG |
| Panel-Modell | AMEJ006 |
| Plattentyp | AM-OLED , OLED |
| Panelgröße | 2.8 inch |
| Auflösung | 240(RGB)×400 , WQVGA |
| aktiver Bereich | 36.72×61.2 mm |
| Umriss | 40.72×69.56×1.2 mm |
| Oberfläche | Glare (Haze 0%), Hard coating |
| Helligkeit | 200 cd/m² (Typ.) |
| Kontrastverhältnis | 2000 : 1 (Typ.) |
| Farben anzeigen | 262K (6-bit), CIE1931106% |
| Blickwinkel | 80/80/80/80 (Typ.)(CR≥200)(L/R/U/D) |
| Frequenz | 60Hz |
| Treiber-IC | Built-in D53E4EA7554 |
| Signalschnittstelle | CPU, 35 pins |
| Eingangsspannung | 2.8/2.8/3.8V (Typ.)(VDD2/VCI/Vbat) |
| Anwendung | MPH |
