| Artikelnummer | LTE283QV-F01 |
| Marke | Samsung |
| Größe | 2.8 |
| Anwendung | PDA |
| Auflösung | 320×240 |
| Komposition | LCM |
| Helligkeit | 250 |
| CR | 350:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | TTL |
| Panel-Marke | SAMSUNG |
| Panel-Modell | LTE283QV-F01 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 2.8 inch |
| Auflösung | 320(RGB)×240 , QVGA |
| Anzeigemodus | PVA, Normally Black, TMR |
| aktiver Bereich | 57.59×43.19 mm |
| Umriss | 64.4×56.5 mm |
| Oberfläche | |
| Helligkeit | 250 cd/m² (Typ.) |
| Kontrastverhältnis | 350 : 1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit) |
| Reaktionszeit | 35 (Typ.)(Tr+Td) |
| Blickwinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 5S1PWLEDWithout Driver |
| Signalschnittstelle | Parallel RGB (1 ch, 8-bit) + SPI, 45 pins |
| Eingangsspannung | 2.8/2.8V (Typ.)(VDC/VCC) |
| Anwendung | PDA |
