| Artikelnummer | LTP500GV-F01 |
| Marke | Samsung |
| Größe | 5.0 |
| Anwendung | PDA |
| Auflösung | 480×640 |
| Komposition | LCM |
| Helligkeit | 200 |
| CR | 250:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | TTL |
| Panel-Marke | SAMSUNG |
| Panel-Modell | LTP500GV-F01 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 5.0 inch |
| Auflösung | 480(RGB)×640 , VGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 75.6×100.8 mm |
| Umriss | 83.84×113.2×4.8 mm |
| Oberfläche | |
| Helligkeit | 200 cd/m² (Typ.) |
| Kontrastverhältnis | 250:1 (Typ.) |
| Farben anzeigen | 262K (6-bit), CIE193140% |
| Reaktionszeit | 35 (Typ.)(Tr+Td) |
| Blickwinkel | 40/30/50/50 (Min.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 3S4PWLEDWithout Driver |
| Signalschnittstelle | Parallel RGB (1 ch, 6-bit), 60 pins |
| Eingangsspannung | 3.3/8.0/16.0/-8.4V (Typ.)(DVDD/AVDD/VGH/VGL) |
| Anwendung | PDA |
