| Artikelnummer | LS030Y3DX01 |
| Marke | SHARP |
| Größe | 3.0 |
| Anwendung | MPH |
| Auflösung | 480×800 |
| Komposition | LCM |
| Helligkeit | 500 |
| CR | 500:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | TTL |
| Panel-Marke | SHARP |
| Panel-Modell | LS030Y3DX01 |
| Plattentyp | CG-Silicon , LCM |
| Panelgröße | 3.0 inch |
| Auflösung | 480(RGB)×800 , WVGA |
| Anzeigemodus | ASV, Normally Black, Transmissive |
| aktiver Bereich | 38.88×64.8 mm |
| Umriss | 45.6×76.4 mm |
| Oberfläche | |
| Helligkeit | 500 cd/m² (Typ.) |
| Kontrastverhältnis | 500:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193175% |
| Reaktionszeit | 11/24 (Typ.)(Tr/Td) |
| Blickwinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 1S6PWLEDWithout Driver |
| Signalschnittstelle | Parallel RGB (1 ch, 8-bit) + SPI, 49 pins |
| Eingangsspannung | 2.8/2.8V (Typ.)(VDDIO/VCC) |
| Anwendung | MPH |
