| Artikelnummer | LS030B3UW01 |
| Marke | SHARP |
| Größe | 3.0 |
| Anwendung | MPH |
| Auflösung | 240×400 |
| Komposition | LCM |
| Helligkeit | 500 |
| CR | 2000:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | CPU |
| Panel-Marke | SHARP |
| Panel-Modell | LS030B3UW01 |
| Plattentyp | CG-Silicon , LCM |
| Panelgröße | 3.0 inch |
| Auflösung | 240(RGB)×400 , WQVGA |
| Anzeigemodus | Normally Black, Transmissive |
| aktiver Bereich | 38.88×64.8 mm |
| Umriss | 43.08×75.4 mm |
| Oberfläche | |
| Helligkeit | 500 cd/m² (Typ.) |
| Kontrastverhältnis | 2000:1 (Typ.) |
| Farben anzeigen | 262K (6-bit), CIE193170% |
| Reaktionszeit | 11/24 (Typ.)(Tr/Td) |
| Blickwinkel | 80/80/80/80 (Typ.)(CR≥5)(L/R/U/D) |
| Lampentyp | 1S6PWLEDWithout Driver |
| Signalschnittstelle | CPU, 40 pins |
| Eingangsspannung | 2.8V (Typ.)(VCC) |
| Anwendung | MPH |
| 30WQF0H | SII | 3.0 | 240×400 |
| A030DN01 V0 | AUO | 3.0 | 320×240 |
| CLAA030HA22DE | CPT | 3.0 | 960×480(dot) |
| EQ030AS181 | PDI | 3.0 | 320×240 |
| LS030B3UW01 | SHARP | 3.0 | 240×400 |
| LS030B3UX01D | SHARP | 3.0 | 240×400 |
| LS030B3UX07 | SHARP | 3.0 | 240×400 |
| LS030Q7DH01 | SHARP | 3.0 | 240×320 |
| LS030Y3DX01 | SHARP | 3.0 | 480×800 |
| LS030Y7PW01 | SHARP | 3.0 |
| AMS395GB01 | Samsung | 4.0 | 360×640 |
| CLAN050LL31 1XG | CPT | 5.0 | 480×800 |
| DLC0300AMG | Other | 3.0 | 240×400 |
| H027QT01 | AUO | 2.7 | 208×320 |
| LH430WV1-SD02 | LG Display | 4.3 | 480×800 |
| LH530WX1-SH02 | LG Display | 5.3 | 720×1280 |
| LQ043Y1DX01 | SHARP | 4.3 | 480×800 |
| TD035STEB1 | TPO | 3.5 | 240×320 |
| TM024HDH36 | Tianma | 2.4 | 240×320 |
| TM030LBHT1 | Tianma | 3.0 | 240×400 |
