| Artikelnummer | CLAN050LL31 1XG |
| Marke | CPT |
| Größe | 5.0 |
| Anwendung | MPH |
| Auflösung | 480×800 |
| Komposition | CELL |
| Helligkeit | 0 |
| CR | 900:1 |
| Farben | |
| Hintergrundbeleuchtung | No B/L |
| Schnittstelle | |
| Panel-Marke | CPT |
| Panel-Modell | CLAN050LL31 1XG 1 Compatible model |
| Plattentyp | a-Si TFT-LCD , CELL |
| Panelgröße | 5.0 inch |
| Auflösung | 480(RGB)×800 , WVGA |
| Anzeigemodus | FFS, Normally Black, Transmissive |
| aktiver Bereich | 65.12×109.2 mm |
| Umriss | 69.92×116.98×0.5 mm |
| Oberfläche | Without Polarizer |
| Glastiefe | 0.25+0.25 mm |
| Durchlässigkeit | 5.1% (Typ.)(without Polarizer) |
| Kontrastverhältnis | 900:1 (Typ.) |
| Farben anzeigen | , CIE193151% |
| Reaktionszeit | 30 (Typ.)(Tr+Td) |
| Blickwinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Treiber-IC | Suggest HX8369-B |
| Anwendung | MPH |
| A050AVV50R0 | Aptus | 5.0 | 800×480 |
| A050VW02 V0 | AUO | 5.0 | 480×800 |
| AT050TN33 | Innolux | 5.0 | 480×272 |
| CLAN050LE61 1XE | CPT | 5.0 | 540×960 |
| CLAN050LH21 1XB | CPT | 5.0 | 540×960 |
| CLAN050LL31 1XG | CPT | 5.0 | 480×800 |
| H497TLB01 | AUO | 5.0 | 720×1280 |
| PA050XS7 | E Ink | 5.0 | 320×234 |
| TM050NDH01 | Tianma | 5.0 | 480×272 |
| TM050QDH07 | Tianma | 5.0 | 640×480 |
| BTL454885-W698L | BOE | 4.5 | 480×854 |
| DLC0400KZG | Other | 4.0 | 640×1136 |
| H466TAN01.0 | AUO | 4.7 | 720×1280 |
| LH450WX3-SD01 | LG Display | 4.5 | 720×1280 |
| LS022Q8UD04 | SHARP | 2.2 | 240×320 |
| LT031MDZ4000 | JDI | 3.1 | 720×720 |
| LT040MDU4100 | TOSHIBA | 4.0 | 480×854 |
| LTM024P339 | TOSHIBA | 2.4 | 240×320 |
| PJ050IA-14A | Innolux | 5.0 | 720×1280 |
| TM020HBH03 | Tianma | 2.0 | 240×320 |
