| Artikelnummer | 30WQF0H |
| Marke | SII |
| Größe | 3.0 |
| Anwendung | HHP |
| Auflösung | 240×400 |
| Komposition | LCM |
| Helligkeit | 450 |
| CR | 800:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | CPU/RGB/SPI |
| Panel-Marke | SII |
| Panel-Modell | 30WQF0H |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 3.0 inch |
| Auflösung | 240(RGB)×400 , WQVGA |
| Anzeigemodus | IPS, Normally Black, Transmissive |
| aktiver Bereich | 39.24×65.4 mm |
| Umriss | 44.5×77.1×2.3 mm |
| Oberfläche | Clear, Hard coating |
| Helligkeit | 450 cd/m² (Typ.) |
| Kontrastverhältnis | 800:1 (Typ.) |
| Farben anzeigen | 262K (6-bit), CIE193168% |
| Reaktionszeit | 35 (Typ.)(Tr+Td) |
| Blickwinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Lampentyp | 5S1PWLED |
| Signalschnittstelle | CPU/RGB/SPI, 51 pins |
| Eingangsspannung | 1.8/3.0V (Typ.)(IOVCC/VCI) |
| Anwendung | HHP |
| 30WQF0H | SII | 3.0 | 240×400 |
| 990000006 | TPO | 3.0 | 320×240 |
| A030DN01 V0 | AUO | 3.0 | 320×240 |
| A030DN05 V0 | AUO | 3.0 | 320×240 |
| C-51505NFJ-SLW-APN | Kyocera | 3.0 | 20×2 |
| C-51505NFQJ-LG-AKN | Kyocera | 3.0 | 20×2 |
| C-51505NFQJ-LW-ALN | Kyocera | 3.0 | 20×2 |
| DLC0300AMG | Other | 3.0 | 240×400 |
| DX08D11VM0AAA | KOE | 3.0 | 480×800 |
| TM030LBHT1 | Tianma | 3.0 | 240×400 |
| 20QVF1H | SII | 2.0 | 240×320 |
| A043FW03 V2 | AUO | 4.3 | 480×272 |
| AM-320240LATNQW-00H-F | AMPIRE | 3.5 | 320×240 |
| CMD500TT10-C1 | ORTUSTECH | 3.2 | 320×240 |
| COM41H4M31XLC | ORTUSTECH | 4.1 | 320×240 |
| DLC0200EUG | Other | 2.0 | 240×320 |
| LS024Q3UX05 | SHARP | 2.4 | 240×320 |
| LS027B7DH01 | SHARP | 2.7 | 400×240 |
| LTM035A776C | TOSHIBA | 3.5 | 240×320 |
| TM047NBH03 | Tianma | 4.7 | 480×272 |
