| Artikelnummer | 990000006 |
| Marke | TPO |
| Größe | 3.0 |
| Anwendung | DSC |
| Auflösung | 320×240 |
| Komposition | LCM |
| Helligkeit | 250 |
| CR | 400:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | Serial RGB |
| Panel-Marke | TPO |
| Panel-Modell | 990000006 |
| Plattentyp | LTPS TFT-LCD , LCM |
| Panelgröße | 3.0 inch |
| Auflösung | 320(RGB)×240 , QVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 65.31×36.84 mm |
| Umriss | 75.31×43.44 mm |
| Oberfläche | Hard coating (3H) |
| Helligkeit | 250 cd/m² (Typ.) |
| Kontrastverhältnis | 400:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193140% |
| Reaktionszeit | 5/11 (Typ.)(Tr/Td) |
| Blickwinkel | 60/60/50/60 (Min.)(CR≥10)(L/R/U/D) |
| Lampentyp | 3S1PWLEDWithout Driver |
| Signalschnittstelle | Serial RGB (8-bit) + SPI, 39 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | DSC |
