| Artikelnummer | TM030CDH51-00 |
| Marke | Tianma |
| Größe | 3.0 |
| Anwendung | DSC |
| Auflösung | 320×240 |
| Komposition | LCM |
| Helligkeit | 250 |
| CR | 500:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | Serial RGB |
| Panel-Marke | TIANMA |
| Panel-Modell | TM030CDH51-00 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 3.0 inch |
| Auflösung | 320(RGB)×240 , QVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 65.52×36.84 mm |
| Umriss | 74.92×42.74 mm |
| Oberfläche | Hard coating |
| Helligkeit | 250 cd/m² (Typ.) |
| Kontrastverhältnis | 500:1 (Typ.) |
| Farben anzeigen | 16.7M (6-bit + Hi-FRC), CIE193143% |
| Reaktionszeit | 30 (Typ.)(Tr+Td) |
| Blickwinkel | 70/60/70/70 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 2S1PWLEDWithout Driver |
| Signalschnittstelle | Serial RGB (8-bit) + SPI, CCIR601/656, 39 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | DSC |
| 990000006 | TPO | 3.0 | 320×240 |
| 990001086 | Innolux | 3.0 | |
| A030DN01 V9 | AUO | 3.0 | 320×240 |
| C-51505NFJ-SLW-APN | Kyocera | 3.0 | 20×2 |
| C-51505NFQJ-LG-AKN | Kyocera | 3.0 | 20×2 |
| DLC0300AMG | Other | 3.0 | 240×400 |
| EQ030AS181 | PDI | 3.0 | 320×240 |
| LH300WQ1-ED01 | LG Display | 3.0 | 240×400 |
| LTM030DH60 | TOSHIBA | 3.0 | 240×427 |
| TM030CDH51-00 | Tianma | 3.0 | 320×240 |
| A015AN03 V0 | AUO | 1.46 | 280×220 |
| A027DN03 V4 | AUO | 2.7 | 320×240 |
| LQ025A3DD01 | SHARP | 2.5 | 480×240 |
| LQ035JC211 | Innolux | 3.5 | 320×240 |
| LS020A8DX02 | SHARP | 2.0 | 320×240 |
| LS027T3DG01 | SHARP | 2.7 | 320×240 |
| TD020THEG1 | TPO | 2.0 | 640×240 |
| TD025THEA3 | TPO | 2.5 | 320×240 |
| TM035KDH16-09 | Tianma | 3.5 | 320×240 |
| UP018D11 | UNIPAC | 1.8 | 528×220(dot) |
