| Artikelnummer | TD020THEG1 |
| Marke | TPO |
| Größe | 2.0 |
| Anwendung | DSC |
| Auflösung | 640×240 |
| Komposition | LCM |
| Helligkeit | 300 |
| CR | 300:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | Serial RGB |
| Panel-Marke | TPO |
| Panel-Modell | TD020THEG1 |
| Plattentyp | LTPS TFT-LCD , LCM |
| Panelgröße | 2.0 inch |
| Auflösung | 640×240 , HVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 40.672×30.48 mm |
| Umriss | 46.1×40.96 mm |
| Oberfläche | Hard coating (3H) |
| Helligkeit | 300 cd/m² (Typ.) |
| Kontrastverhältnis | 300:1 (Typ.) |
| Farben anzeigen | 16.7M (6-bit + Dithering) |
| Reaktionszeit | 13/22 (Typ.)(Tr/Td) |
| Blickwinkel | 40/40/20/50 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 1 pcsWLEDWithout Driver |
| Signalschnittstelle | Analog RGB + LVDS (1 ch, 6-bit), 40 pins |
| Eingangsspannung | 3.0V (Typ.) |
| Anwendung | DSC |
