| Artikelnummer | OEL9M0064-G-E |
| Marke | Other |
| Größe | 2.0 |
| Anwendung | IA |
| Auflösung | 128×32 |
| Komposition | OLED |
| Helligkeit | |
| CR | 10000:1 |
| Farben | Mono(Green) |
| Hintergrundbeleuchtung | self |
| Schnittstelle | CPU/SPI/I²C |
| Panel-Marke | TRULY |
| Panel-Modell | OEL9M0064-G-E |
| Plattentyp | PM-OLED , OLED |
| Panelgröße | 2.0 inch |
| Auflösung | 128×32 |
| aktiver Bereich | 50.535×10.695 mm |
| Umriss | 59×18.86×1.55 mm |
| Oberfläche | |
| Helligkeit | |
| Kontrastverhältnis | 10000 : 1 (Min.) |
| Farben anzeigen | Mono(Green) (1-bit) |
| Blickwinkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| Frequenz | 100Hz |
| Treiber-IC | TAB Built-in SSD1305T7R1 |
| Signalschnittstelle | 8-bit 6800/8080 parallel, SPI, I²C, 31 pins |
| Anwendung | IA |
