| Artikelnummer | LQ020B3DC01 |
| Marke | SHARP |
| Größe | 2.0 |
| Anwendung | MPH |
| Auflösung | 176×220 |
| Komposition | LCM |
| Helligkeit | 300 |
| CR | 350:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | TTL |
| Panel-Marke | SHARP |
| Panel-Modell | LQ020B3DC01 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 2.0 inch |
| Auflösung | 176(RGB)×220 , QCIF+ |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 31.68×39.6 mm |
| Umriss | 37.8×53×2.9 mm |
| Oberfläche | |
| Helligkeit | 300 cd/m² (Typ.) |
| Kontrastverhältnis | 350:1 (Typ.) |
| Farben anzeigen | 262K (6-bit), CIE193160% |
| Reaktionszeit | 10/25 (Typ.)(Tr/Td) |
| Blickwinkel | 60/60/60/45 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 3S1PWLEDWithout Driver |
| Signalschnittstelle | Parallel RGB (1 ch, 6-bit), 39 pins |
| Eingangsspannung | 2.85/2.85V (Typ.)(VDDIO/VCI) |
| Anwendung | MPH |
