| Artikelnummer | TM055JDHP71 |
| Marke | Tianma |
| Größe | 5.5 |
| Anwendung | MPH |
| Auflösung | 720×1280 |
| Komposition | LCM |
| Helligkeit | 450 |
| CR | 900:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | MIPI |
| Panel-Marke | TIANMA |
| Panel-Modell | TM055JDHP71 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 5.5 inch |
| Auflösung | 720(RGB)×1280 , WXGA |
| Anzeigemodus | SFT, Normally Black, Transmissive |
| aktiver Bereich | 68.04×120.96 mm |
| Umriss | 71.14×130.76 mm |
| Oberfläche | |
| Helligkeit | 450 cd/m² (Typ.) |
| Kontrastverhältnis | 900:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193172% |
| Reaktionszeit | 35 (Max.)(Tr+Td) |
| Blickwinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 6S2PWLEDWithout Driver |
| Signalschnittstelle | MIPI (4 data lanes), 30 pins |
| Eingangsspannung | 1.8/5.5/-5.5V (Typ.)(IOVCC/VSP/VSN) |
| Anwendung | MPH |
