| Artikelnummer | LQ055T3SX02 |
| Marke | SHARP |
| Größe | 5.5 |
| Anwendung | MPH |
| Auflösung | 1080×1920 |
| Komposition | LCM |
| Helligkeit | 450 |
| CR | 1000:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | MIPI |
| Panel-Marke | SHARP |
| Panel-Modell | LQ055T3SX02 |
| Plattentyp | IGZO TFT-LCD , LCM |
| Panelgröße | 5.5 inch |
| Auflösung | 1080(RGB)×1920 , FHD |
| Anzeigemodus | New Mode2, Normally Black, Transmissive |
| aktiver Bereich | 68.04×120.96 mm |
| Umriss | 70.84×128.56×1.65 mm |
| Oberfläche | |
| Helligkeit | 450 cd/m² (Typ.) |
| Kontrastverhältnis | 1000:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193170% |
| Reaktionszeit | 35 (Typ.)(Tr+Td) |
| Blickwinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 6S2PWLEDWithout Driver |
| Signalschnittstelle | MIPI (4 data lanes), 39 pins |
| Eingangsspannung | 1.8/5.8/5.6V (Typ.)(VDDI/VSP/VSN) |
| Anwendung | MPH |
| LM6Q35 | SHARP | 5.5 | 320×240 |
| LQ055K3SX02 | SHARP | 5.5 | 720×1280 |
| LQ055T3SX02 | SHARP | 5.5 | 1080×1920 |
| LQ055T3SX02Z | SHARP | 5.5 | 1080×1920 |
| LQ055T3SX04 | SHARP | 5.5 | 1080×1920 |
| LQ055W1GC01 | SHARP | 5.5 | 1024×600 |
| LS055R1SX03 | SHARP | 5.5 | 1440×2560 |
| LS055T3SX05 | SHARP | 5.5 | 1080×1920 |
| NL3224AC35-01 | NLT | 5.5 | 320×240 |
| TM055XDHP10 | Tianma | 5.5 | 540×960 |
| DLC0220KZG | Other | 2.2 | 320×320 |
| H546TAN01.0 | AUO | 5.5 | 720×1280 |
| L5F30774P01 | Epson | 2.6 | 240×320 |
| LH470WX6-SD01 | LG Display | 4.7 | 750×1334 |
| LH530QH1-SD01 | LG Display | 5.3 | 1440×2560 |
| LQ047K3SX06 | SHARP | 4.7 | 720×1280 |
| LS047T1SC01K | SHARP | 4.7 | 1080×1920 |
| TD028STEB2 | TPO | 2.8 | 240×320 |
| TFT240320-237-E | Other | 2.8 | 240×320 |
| TP241MC01G | Neoview Kolon | 2.4 | 240×320 |
