| Artikelnummer | LQ047K3SX06 |
| Marke | SHARP |
| Größe | 4.7 |
| Anwendung | MPH |
| Auflösung | 720×1280 |
| Komposition | LCM |
| Helligkeit | 450 |
| CR | 1000:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | MIPI |
| Panel-Marke | SHARP |
| Panel-Modell | LQ047K3SX06 |
| Plattentyp | IGZO TFT-LCD , LCM |
| Panelgröße | 4.7 inch |
| Auflösung | 720(RGB)×1280 , WXGA |
| Anzeigemodus | New Mode2, Normally Black, Transmissive |
| aktiver Bereich | 58.104×103.296 mm |
| Umriss | 61.05×112.09×1.52 mm |
| Oberfläche | Hard coating (3H) |
| Helligkeit | 450 cd/m² (Typ.) |
| Kontrastverhältnis | 1000:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193170% |
| Reaktionszeit | 30 (Typ.)(Tr+Td) |
| Blickwinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 10S1PWLEDWithout Driver |
| Signalschnittstelle | MIPI (4 data lanes), 40 pins |
| Eingangsspannung | 1.8/5.0/-5.0V (Typ.)(IOVCC/AVDD/AVEE) |
| Anwendung | MPH |
