| Artikelnummer | LH530QH1-SD01 |
| Marke | LG Display |
| Größe | 5.3 |
| Anwendung | MPH |
| Auflösung | 1440×2560 |
| Komposition | Assembly |
| Helligkeit | 500 |
| CR | 1500:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | MIPI |
| Panel-Marke | LG Display |
| Panel-Modell | LH530QH1-SD01 |
| Plattentyp | LTPS TFT-LCD , Assembly |
| Panelgröße | 5.3 inch |
| Auflösung | 1440(RGB)×2560 , Quad-HD |
| aktiver Bereich | 65.88×117.12 mm |
| Umriss | 70.3×135.19×1.86 mm |
| Oberfläche | Hard coating |
| Helligkeit | 500 cd/m² (Typ.) |
| Kontrastverhältnis | 1500:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193185% |
| Blickwinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Signalschnittstelle | MIPI (2 ch, 4 data lanes), 54 pins |
| Eingangsspannung | 1.8/3.3/5.4/-5.4V (Typ.)(VDDI/VPNL/DDVDH/DDVDL) |
| Anwendung | MPH |
