| Artikelnummer | PJ045IC-01F |
| Marke | Innolux |
| Größe | 4.5 |
| Anwendung | MPH |
| Auflösung | 720×1280 |
| Komposition | LCM |
| Helligkeit | 380 |
| CR | 800:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | MIPI |
| Panel-Marke | CHIMEI INNOLUX |
| Panel-Modell | PJ045IC-01F |
| Plattentyp | LTPS TFT-LCD , LCM |
| Panelgröße | 4.5 inch |
| Auflösung | 720(RGB)×1280 , WXGA |
| Anzeigemodus | IPS, Normally Black, Transmissive |
| aktiver Bereich | 55.512×98.688 mm |
| Umriss | 60.04×108.72 mm |
| Oberfläche | |
| Helligkeit | 380 cd/m² (Typ.) |
| Kontrastverhältnis | 800:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193170% |
| Reaktionszeit | 25 (Typ.)(Tr+Td) |
| Blickwinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 5S2PWLEDWithout Driver |
| Signalschnittstelle | MIPI (4 data lanes), 30 pins |
| Eingangsspannung | 1.8/2.8V (Typ.)(VDDIO/VCI) |
| Anwendung | MPH |
