| Artikelnummer | L5S30883P00 |
| Marke | SANYO |
| Größe | 4.5 |
| Anwendung | CNS |
| Auflösung | 480×240 |
| Komposition | LCM |
| Helligkeit | 400 |
| CR | 300:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | TTL |
| Panel-Marke | SANYO |
| Panel-Modell | L5S30883P00 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 4.5 inch |
| Auflösung | 480(RGB)×240 , WQVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 99.36×56.04 mm |
| Umriss | 112.7×70.2 mm |
| Oberfläche | Glare (Haze 0%) |
| Helligkeit | 400 cd/m² (Typ.) |
| Kontrastverhältnis | 300:1 (Typ.) |
| Farben anzeigen | 262K (6-bit) |
| Reaktionszeit | 10/20 (Typ.)(Tr/Td) |
| Blickwinkel | 55/55/45/55 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | WLEDEmbedded (LED Driver) |
| Signalschnittstelle | Parallel RGB (1 ch, 6-bit), 40 pins |
| Eingangsspannung | 3.3V (Typ.) |
| rohs: | |
| Anwendung | CNS |
