| Artikelnummer | CLAA102NA01CW |
| Marke | CPT |
| Größe | 10.2 |
| Anwendung | CNS |
| Auflösung | 1024×600 |
| Komposition | LCM |
| Helligkeit | 400 |
| CR | 400:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | LVDS |
| Panel-Marke | CPT |
| Panel-Modell | CLAA102NA01CW |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 10.2 inch |
| Auflösung | 1024(RGB)×600 , WSVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 222.72×130.5 mm |
| Umriss | 235×145.8 mm |
| Oberfläche | Antiglare |
| Helligkeit | 400 cd/m² (Typ.) |
| Kontrastverhältnis | 400:1 (Typ.) |
| Farben anzeigen | 262K (6-bit) |
| Reaktionszeit | 25 (Max.)(Tr+Td) |
| Blickwinkel | 70/70/40/70 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 1 pcsCCFLWithout Driver |
| Signalschnittstelle | LVDS (1 ch, 6-bit), 30 pins |
| Eingangsspannung | 3.3V (Typ.) |
| rohs: | |
