| Artikelnummer | H381DLN01.0 |
| Marke | AUO |
| Größe | 3.8 |
| Anwendung | MPH |
| Auflösung | 1080×1200 |
| Komposition | OLED |
| Helligkeit | 100 |
| CR | 3000:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | self |
| Schnittstelle | MIPI |
| Panel-Marke | AUO |
| Panel-Modell | H381DLN01.0 |
| Plattentyp | AM-OLED , OLED |
| Panelgröße | 3.8 inch |
| Auflösung | 1080(RGB)×1200 |
| aktiver Bereich | 64.8×72 mm |
| Umriss | 67.6×78.95×1.24 mm |
| Oberfläche | |
| Helligkeit | 100 cd/m² (Typ.) |
| Kontrastverhältnis | 3000 : 1 (Min.) |
| Farben anzeigen | 16.7M (8-bit), CIE1931100% |
| Blickwinkel | 80/80/80/80 (Typ.)(CR≥480)(L/R/U/D) |
| Treiber-IC | COG Built-in RM69071 |
| Signalschnittstelle | MIPI (4 data lanes), 39 pins |
| Eingangsspannung | 1.8/4.6/5.8/-2.9V (Typ.)(IOVCC/OVDD/AVDD/OVSS) |
| Anwendung | MPH |
| H380VW01 V2 | AUO | 3.8 | 480×800 |
| H381DLN01.0 | AUO | 3.8 | 1080×1200 |
| KCS038AA1AG-G21 | Kyocera | 3.8 | 240×320 |
| KHS038AA1AA-B70R-57-11 | Kyocera | 3.8 | 240×320 |
| LQ038B3DD01 | SHARP | 3.8 | 320×480 |
| LQ038J7DH52 | SHARP | 3.8 | 320×480 |
| LQ038Q5DR01 | SHARP | 3.8 | 320×240 |
| LQ038Q7DB03 | SHARP | 3.8 | 240×320 |
| LQ038Q7DB03A | SHARP | 3.8 | 240×320 |
| TM038QV-67A03 | SANYO | 3.8 | 320×240 |
| H466TAN01.1 | AUO | 4.7 | 720×1280 |
| LH320WV3-SH02 | LG Display | 3.2 | 480×800 |
| LH450WX1-SD01 | LG Display | 4.5 | 720×1280 |
| LH500WF1-SD02 | LG Display | 5.0 | 1080×1920 |
| LH530WX1-SH02 | LG Display | 5.3 | 720×1280 |
| LQ055T3SX04 | SHARP | 5.5 | 1080×1920 |
| LS036Y1LX03 | SHARP | 3.6 | 480×800 |
| TD025THED2 | TPO | 2.5 | 320×240 |
| TM022GDH11 | Tianma | 2.2 | 176×220 |
| TM035PDZ00 | Tianma | 3.5 | 320×480 |
