| Artikelnummer | TM038QV-67A03 |
| Marke | SANYO |
| Größe | 3.8 |
| Anwendung | PDA |
| Auflösung | 320×240 |
| Komposition | LCM |
| Helligkeit | |
| CR | |
| Farben | 262K |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | TTL |
| Panel-Marke | TORISAN |
| Panel-Modell | TM038QV-67A03 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 3.8 inch |
| Auflösung | 320(RGB)×240 , QVGA |
| Anzeigemodus | TN, Normally White, Reflective |
| aktiver Bereich | 76.8×57.6 mm |
| Umriss | 96.8×73 mm |
| Oberfläche | |
| Helligkeit | |
| Kontrastverhältnis | |
| Farben anzeigen | 262K (6-bit) |
| Reaktionszeit | 10/10 (Typ.)(Tr/Td) |
| Blickwinkel | 60/60/50/50 (Typ.)(CR≥2)(L/R/U/D) |
| Lampentyp | 1 pcsCCFLWithout Driver |
| Signalschnittstelle | Parallel RGB (1 ch, 6-bit), 90 pins |
| Eingangsspannung | 3.3/5/14.3/-10V (Typ.)(VDD/VCC/VGH/VGL) |
| Anwendung | PDA |
