| Artikelnummer | LQ055T3SX04 |
| Marke | SHARP |
| Größe | 5.5 |
| Anwendung | MPH |
| Auflösung | 1080×1920 |
| Komposition | CELL |
| Helligkeit | 0 |
| CR | 1000:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | No B/L |
| Schnittstelle | |
| Panel-Marke | SHARP |
| Panel-Modell | LQ055T3SX04 |
| Plattentyp | IGZO TFT-LCD , CELL |
| Panelgröße | 5.5 inch |
| Auflösung | 1080(RGB)×1920 , FHD |
| Anzeigemodus | New Mode2, Normally Black, Transmissive |
| aktiver Bereich | 68.04×120.96 mm |
| Umriss | 70.84×128.16 mm |
| Oberfläche | |
| Glastiefe | 0.20+0.20 mm |
| Durchlässigkeit | 4.2% (Typ.)(with Polarizer) |
| Kontrastverhältnis | 1000:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193170% |
| Reaktionszeit | 35 (Max.)(Tr+Td) |
| Blickwinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Treiber-IC | COG Built-in NT35532 |
| Anwendung | MPH |
