| Artikelnummer | TD035SHED1 |
| Marke | TPO |
| Größe | 3.5 |
| Anwendung | MPH |
| Auflösung | 480×640 |
| Komposition | LCM |
| Helligkeit | 170 |
| CR | 200:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | TTL |
| Panel-Marke | TPO |
| Panel-Modell | TD035SHED1 |
| Plattentyp | LTPS TFT-LCD , LCM |
| Panelgröße | 3.5 inch |
| Auflösung | 480(RGB)×640 , VGA |
| Anzeigemodus | TN, Normally White, Transflective |
| aktiver Bereich | 53.28×71.04 mm |
| Umriss | 64×85 mm |
| Oberfläche | |
| Helligkeit | 170 cd/m² (Typ.) |
| Kontrastverhältnis | 200:1 (Typ.)(Transmissive)8:1 (Typ.)(Reflective) |
| Farben anzeigen | 262K (6-bit), CIE193137% |
| Reaktionszeit | 35 (Typ.)(Tr+Td) |
| Blickwinkel | 80/80/80/70 (Typ.)(CR≥10)(L/R/U/D) |
| Lampentyp | 6S1PWLEDWithout Driver |
| Signalschnittstelle | Parallel RGB (1 ch, 6-bit) + SPI, 51 pins |
| Eingangsspannung | 3.0/3.0V (Typ.)(VDC/VDDIO) |
| Anwendung | MPH |
