| Artikelnummer | DLC0350BMG-1 |
| Marke | Other |
| Größe | 3.5 |
| Anwendung | MPH |
| Auflösung | 240×320 |
| Komposition | LCM |
| Helligkeit | 100 |
| CR | 150:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | TTL |
| Panel-Marke | DLC |
| Panel-Modell | DLC0350BMG-1 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 3.5 inch |
| Auflösung | 240(RGB)×320 , QVGA |
| Anzeigemodus | TN, Normally White, Transflective |
| aktiver Bereich | 53.64×71.52 mm |
| Umriss | 64×85×3.13 mm |
| Oberfläche | Hard coating |
| Helligkeit | 100 cd/m² (Typ.) |
| Kontrastverhältnis | 150:1 (Typ.)(Transmissive)6.5:1 (Typ.)(Reflective) |
| Farben anzeigen | 262K (6-bit) |
| Reaktionszeit | 35 (Typ.)(Tr+Td) |
| Blickwinkel | 40/45/55/40 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 6S1PWLEDWithout Driver |
| Signalschnittstelle | Parallel RGB (1 ch, 6-bit) + SPI, 50 pins |
| Eingangsspannung | 2.8/15/-10V (Typ.)(VCC/VGH/VGL) |
| Anwendung | MPH |
