| Artikelnummer | LD043WV1-SP01 |
| Marke | LG Display |
| Größe | 4.3 |
| Anwendung | MPH |
| Auflösung | 480×854 |
| Komposition | LCM |
| Helligkeit | 440 |
| CR | 700:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | TTL |
| Panel-Marke | LG Display |
| Panel-Modell | LD043WV1-SP01 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 4.3 inch |
| Auflösung | 480(RGB)×854 , FWVGA |
| Anzeigemodus | IPS, Normally Black, Transmissive |
| aktiver Bereich | 53.568×96.306 mm |
| Umriss | 59.97×107.31 mm |
| Oberfläche | Glare (Haze 0%) |
| Helligkeit | 440 cd/m² (Typ.) |
| Kontrastverhältnis | 700:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit) |
| Reaktionszeit | 30 (Typ.)(Tr+Td) |
| Blickwinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Lampentyp | 4S2PWLEDWithout Driver |
| Signalschnittstelle | Parallel RGB (1 ch, 8-bit) + SPI, 60 pins |
| Eingangsspannung | 3.0/1.8V (Typ.)(VIC/VDDI) |
| Anwendung | MPH |
