| Artikelnummer | H027QT01 |
| Marke | AUO |
| Größe | 2.7 |
| Anwendung | MPH |
| Auflösung | 208×320 |
| Komposition | LCM |
| Helligkeit | 60 |
| CR | 50:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | TTL |
| Panel-Marke | AU Optronics |
| Panel-Modell | H027QT01 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 2.7 inch |
| Auflösung | 208(RGB)×320 |
| Anzeigemodus | TN, Normally White, Transflective |
| aktiver Bereich | 36.816×56.64 mm |
| Umriss | 45.8×69.17 mm |
| Oberfläche | |
| Helligkeit | 60 cd/m² (Typ.) |
| Kontrastverhältnis | 50:1 (Typ.)(Transmissive)20:1 (Typ.)(Reflective) |
| Farben anzeigen | 262K (6-bit) |
| Reaktionszeit | 10/30 (Typ.)(Tr/Td) |
| Blickwinkel | 45/45/45/45 (Typ.)(CR≥10)(L/R/U/D) |
| Lampentyp | 2S2PWLEDWithout Driver |
| Signalschnittstelle | Parallel RGB (1 ch, 6-bit), 60 pins |
| Eingangsspannung | 3.3/5/5/3.3/12/-12V (Typ.)(DVCC/AVDD/AVDD1/AVDD2/VGH/VGL) |
| Anwendung | MPH |
