| Artikelnummer | H020HD01 V0 |
| Marke | AUO |
| Größe | 2.0 |
| Anwendung | MPH |
| Auflösung | 176×220 |
| Komposition | OLED |
| Helligkeit | 105 |
| CR | 10000:1 |
| Farben | 65K/262K |
| Hintergrundbeleuchtung | self |
| Schnittstelle | CPU |
| Panel-Marke | AUO |
| Panel-Modell | H020HD01 V0 |
| Plattentyp | AM-OLED , OLED |
| Panelgröße | 2.0 inch |
| Auflösung | 176(RGB)×220 , QCIF+ |
| aktiver Bereich | 31.152×38.94 mm |
| Umriss | 39.52×53.2 mm |
| Oberfläche | Hard coating |
| Helligkeit | 105 cd/m² (Typ.) |
| Kontrastverhältnis | 10000 : 1 (Typ.) |
| Farben anzeigen | 65K/262K (6-bit), CIE193168% |
| Blickwinkel | 30/30/30/30 (Typ.)(CR≥2)(L/R/U/D) |
| Treiber-IC | Built-in uPD161621 + uPD161644 |
| Signalschnittstelle | CPU, 34 pins |
| Eingangsspannung | 3.3/-7.0V (Typ.)(VCC/VSS) |
| Anwendung | MPH |
