| Artikelnummer | TM030LBHT1 |
| Marke | Tianma |
| Größe | 3.0 |
| Anwendung | MPH |
| Auflösung | 240×400 |
| Komposition | LCM |
| Helligkeit | 130 |
| CR | 100:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | CPU/RGB/SPI |
| Panel-Marke | TIANMA |
| Panel-Modell | TM030LBHT1 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 3.0 inch |
| Auflösung | 240(RGB)×400 , WQVGA |
| Anzeigemodus | ECB, Normally White, Transflective |
| aktiver Bereich | 38.88×64.8 mm |
| Umriss | 47.28×76.4 mm |
| Oberfläche | |
| Helligkeit | 130 cd/m² (Typ.) |
| Kontrastverhältnis | 100:1 (Typ.)(Transmissive)8:1 (Typ.)(Reflective) |
| Farben anzeigen | 262K (6-bit) |
| Reaktionszeit | 35 (Typ.)(Tr+Td) |
| Blickwinkel | 40/45/55/40 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 4S1PWLEDWithout Driver |
| Signalschnittstelle | CPU/RGB/SPI, 45 pins |
| Eingangsspannung | 2.8/2.8V (Typ.)(VCC/IOVCC) |
| Anwendung | MPH |
| A030DN05 V0 | AUO | 3.0 | 320×240 |
| LQ31E05 | SHARP | 3.0 | 383×234 |
| LS030B3UX01D | SHARP | 3.0 | 240×400 |
| LS030Q7DH01 | SHARP | 3.0 | 240×320 |
| TD030MHEB3 | TPO | 3.0 | 320×240 |
| TM030CDH51-00 | Tianma | 3.0 | 320×240 |
| TM030LBHT1 | Tianma | 3.0 | 240×400 |
| TM030LDHT1 | Tianma | 3.0 | 240×400 |
| TM030LDHT2 | Tianma | 3.0 | 240×400 |
| TM030ZDHG01 | Tianma | 3.0 | 320×320 |
| AMCE002 | Samsung | 2.4 | 240×320 |
| BTL282440-310L | BOE | 2.8 | 240×400 |
| C0240QGLG-T | CMEL | 2.4 | 240×320 |
| LMS246GF06 | Samsung | 2.5 | 320×240 |
| LMS320HF46 | Samsung | 3.2 | 240×432 |
| LQ055T3SX02Z | SHARP | 5.5 | 1080×1920 |
| LS059T1SX01 | SHARP | 5.9 | 1080×1920 |
| LTP283QV-F04 | Samsung | 2.8 | 240×320 |
| TD025THEB5 | TPO | 2.5 | 320×240 |
| TM028LDH01 | Tianma | 2.8 | 240×400 |
