| Artikelnummer | TM030LDHT1 |
| Marke | Tianma |
| Größe | 3.0 |
| Anwendung | HHP |
| Auflösung | 240×400 |
| Komposition | LCM |
| Helligkeit | 130 |
| CR | 100:1 |
| Farben | 65K/262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | CPU/RGB/SPI |
| Panel-Marke | TIANMA |
| Panel-Modell | TM030LDHT1 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 3.0 inch |
| Auflösung | 240(RGB)×400 , WQVGA |
| Anzeigemodus | ECB, Normally White, Transflective |
| aktiver Bereich | 38.88×64.8 mm |
| Umriss | 47.28×76.4 mm |
| Oberfläche | Clear, Hard coating (3H) |
| Helligkeit | 130 cd/m² (Typ.) |
| Kontrastverhältnis | 100:1 (Typ.)(Transmissive)8:1 (Typ.)(Reflective) |
| Farben anzeigen | 65K/262K , CIE193134% |
| Reaktionszeit | 35 (Typ.)(Tr+Td) |
| Blickwinkel | 40/45/55/40 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 4S1PWLEDWithout Driver |
| Signalschnittstelle | CPU/RGB/SPI, 45 pins |
| Eingangsspannung | 2.8/2.8V (Typ.)(IOVCC/VCC) |
| Anwendung | HHP |
