| Artikelnummer | S035V01 |
| Marke | CDTECH |
| Größe | 3.5 |
| Anwendung | HHP |
| Auflösung | 480×640 |
| Komposition | LCM |
| Helligkeit | 800 |
| CR | 500:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | CPU/RGB/SPI |
| Panel-Marke | CDTECH |
| Panel-Modell | S035V01 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 3.5 inch |
| Auflösung | 480(RGB)×640 , VGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 53.28×71.04 mm |
| Umriss | 64×85 mm |
| Oberfläche | |
| Helligkeit | 800 cd/m² (Typ.) |
| Kontrastverhältnis | 500:1 (Typ.) |
| Farben anzeigen | 262K (6-bit) |
| Reaktionszeit | 25 (Typ.)(Tr+Td) |
| Blickwinkel | 65/65/55/65 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 4S2PWLEDWithout Driver |
| Signalschnittstelle | CPU/RGB/SPI, 61 pins |
| Eingangsspannung | 3.3/3.3V (Typ.)(VCC/IOVCC) |
| Anwendung | HHP |
