| Artikelnummer | LTM035A776C |
| Marke | TOSHIBA |
| Größe | 3.5 |
| Anwendung | HHP |
| Auflösung | 240×320 |
| Komposition | LCM |
| Helligkeit | 40 |
| CR | |
| Farben | 262K |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | TTL |
| Panel-Marke | Toshiba Matsushita |
| Panel-Modell | LTM035A776C |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 3.5 inch |
| Auflösung | 240(RGB)×320 , QVGA |
| Anzeigemodus | TN, Normally White, Reflective |
| aktiver Bereich | 53.64×71.52 mm |
| Umriss | 70×92.2×5.35 mm |
| Oberfläche | |
| Helligkeit | 40 cd/m² (Typ.) |
| Kontrastverhältnis | 15:1 (Typ.)(Reflective) |
| Farben anzeigen | 262K (6-bit) |
| Reaktionszeit | 50/50 (Max.)(Tr/Td) |
| Blickwinkel | |
| Lampentyp | 1 pcsCCFLWithout Driver |
| Signalschnittstelle | Parallel RGB (1 ch, 6-bit), 50 pins |
| Eingangsspannung | 3.3/5.0/15.0/-12.0/(VGL+3.3)V (Typ.)(DVDD/AVDD/VGH/VGL/GVDD) |
| Anwendung | HHP |
