| Artikelnummer | LS024Q3UX05 |
| Marke | SHARP |
| Größe | 2.4 |
| Anwendung | HHP |
| Auflösung | 240×320 |
| Komposition | LCM |
| Helligkeit | 500 |
| CR | 400:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | CPU |
| Panel-Marke | SHARP |
| Panel-Modell | LS024Q3UX05 |
| Plattentyp | CG-Silicon , LCM |
| Panelgröße | 2.4 inch |
| Auflösung | 240(RGB)×320 , QVGA |
| Anzeigemodus | Normally Black, Transmissive |
| aktiver Bereich | 36.72×48.96 mm |
| Umriss | 42.2×69.4 mm |
| Oberfläche | |
| Helligkeit | 500 cd/m² (Typ.) |
| Kontrastverhältnis | 400:1 (Typ.) |
| Farben anzeigen | 262K , CIE193170% |
| Reaktionszeit | 11/24 (Typ.)(Tr/Td) |
| Blickwinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Lampentyp | 1S5PWLEDWithout Driver |
| Signalschnittstelle | CPU, 37 pins |
| Eingangsspannung | 2.62/2.62V (Typ.)(VDDIO/VDC) |
| Anwendung | HHP |
