| Artikelnummer | LS024J3LX01 |
| Marke | SHARP |
| Größe | 2.4 |
| Anwendung | MPH |
| Auflösung | 320×480 |
| Komposition | LCM |
| Helligkeit | 370 |
| CR | 540:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | MDDI |
| Panel-Marke | SHARP |
| Panel-Modell | LS024J3LX01 |
| Plattentyp | CG-Silicon , LCM |
| Panelgröße | 2.4 inch |
| Auflösung | 320(RGB)×480 , HVGA |
| Anzeigemodus | Normally Black, Transmissive |
| aktiver Bereich | 33.6×50.4 mm |
| Umriss | 38.6×60.4 mm |
| Oberfläche | |
| Helligkeit | 370 cd/m² (Typ.) |
| Kontrastverhältnis | 540:1 (Typ.) |
| Farben anzeigen | 16.7M , CIE193181% |
| Reaktionszeit | 7/15 (Typ.)(Tr/Td) |
| Blickwinkel | |
| Frequenz | 60Hz |
| Lampentyp | 4S1PWLEDWithout Driver |
| Signalschnittstelle | MDDI (2 data lanes), 24 pins |
| Eingangsspannung | 1.65/2.6 (Typ.)(VDD/VDDI) |
| Anwendung | MPH |
