| Artikelnummer | LS024Q8DD92 |
| Marke | SHARP |
| Größe | 2.4 |
| Anwendung | |
| Auflösung | 240×320 |
| Komposition | CELL |
| Helligkeit | 0 |
| CR | 100:1 |
| Farben | 65K/262K |
| Hintergrundbeleuchtung | No B/L |
| Schnittstelle | TTL |
| Panel-Marke | SHARP |
| Panel-Modell | LS024Q8DD92 |
| Plattentyp | CG-Silicon , CELL |
| Panelgröße | 2.4 inch |
| Auflösung | 240(RGB)×320 , QVGA |
| Anzeigemodus | TN, Normally White, Transflective |
| aktiver Bereich | 36.72×48.96 mm |
| Umriss | 41.2×58 mm |
| Oberfläche | Hard coating (3H) |
| Glastiefe | 0.50+0.50 mm |
| Kontrastverhältnis | 100:1 (Typ.)(Transmissive)8:1 (Typ.)(Reflective) |
| Farben anzeigen | 65K/262K |
| Reaktionszeit | 13/35 (Typ.)(Tr/Td) |
| Blickwinkel | 45/45/35/45 (Typ.)(CR≥3)(L/R/U/D) |
| Treiber-IC | Built-in uPD161831 |
| Signalschnittstelle | Parallel RGB (1 ch, 6-bit), 60 pins |
| Eingangsspannung | 3.0/3.0V (Typ.)(VCC/VDC) |
