| Artikelnummer | LQ035Q7DB03F |
| Marke | SHARP |
| Größe | 3.5 |
| Anwendung | HHP |
| Auflösung | 240×320 |
| Komposition | LCM |
| Helligkeit | 55 |
| CR | 85:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | TTL |
| Panel-Marke | SHARP |
| Panel-Modell | LQ035Q7DB03F |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 3.5 inch |
| Auflösung | 240(RGB)×320 , QVGA |
| Anzeigemodus | TN, Normally White, Transflective |
| aktiver Bereich | 53.64×71.52 mm |
| Umriss | 65×85×3.7 mm |
| Oberfläche | Hard coating (3H) |
| Helligkeit | 55 cd/m² (Typ.) |
| Kontrastverhältnis | 85:1 (Typ.)(Transmissive)15:1 (Typ.)(Reflective) |
| Farben anzeigen | 262K (6-bit) |
| Reaktionszeit | 30/50 (Typ.)(Tr/Td) |
| Blickwinkel | 40/40/40/50 (Typ.)(CR≥2)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | WLEDWithout Driver |
| Signalschnittstelle | Parallel RGB (1 ch, 6-bit), 50 pins |
| Eingangsspannung | 5.0/3.3/15.0/-10.0V (Typ.)(VSHA/VSHD/VDD/VEE) |
| Anwendung | HHP |
| LQ035Q1DG02 | SHARP | 3.5 | 320×240 |
| LQ035Q1DG04 | SHARP | 3.5 | 320×240 |
| LQ035Q1DH02 | SHARP | 3.5 | 320×240 |
| LQ035Q3DG02A | SHARP | 3.5 | 320×240 |
| LQ035Q5DG01 | SHARP | 3.5 | 320×240 |
| LQ035Q5DG11 | SHARP | 3.5 | 320×240 |
| LQ035Q7DB03F | SHARP | 3.5 | 240×320 |
| LQ035Q7DB04 | SHARP | 3.5 | 240×320 |
| LQ035Q7DH05 | SHARP | 3.5 | 240×320 |
| LQ035Q7DH06 | SHARP | 3.5 | 240×320 |
| 32NHF0H | SII | 3.2 | 360×640 |
| DLC0350AMG-4 | Other | 3.5 | 320×240 |
| DLC0430NZG-T-1 | Other | 4.3 | 480×272 |
| LQ035Q7DB02R | SHARP | 3.5 | 240×320 |
| LQ035Q7DB05 | SHARP | 3.5 | 240×320 |
| LQ038B7DB01 | SHARP | 3.8 | 320×480 |
| LS024Q3UX05 | SHARP | 2.4 | 240×320 |
| LS037V7DW02 | SHARP | 3.7 | 480×640 |
| T-51963GD035J-MLW-AJN | Kyocera | 3.5 | 240×320 |
| TFTMD030011 | JDI | 3.0 | 720×480 |
