| Artikelnummer | T-55343GD035JU-LW-AFN |
| Marke | Kyocera |
| Größe | 3.5 |
| Anwendung | HHP |
| Auflösung | 320×240 |
| Komposition | LCM |
| Helligkeit | 360 |
| CR | 700:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | TTL |
| Panel-Marke | OPTREX |
| Panel-Modell | T-55343GD035JU-LW-AFN |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 3.5 inch |
| Auflösung | 320(RGB)×240 , QVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 70.08×52.56 mm |
| Umriss | 79×65×4.2 mm |
| Oberfläche | Antiglare |
| Helligkeit | 360 cd/m² (Typ.) |
| Kontrastverhältnis | 700:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit) |
| Reaktionszeit | 8/15 (Typ.)(Tr/Td) |
| Blickwinkel | 80/80/80/80 (Typ.)(CR≥5)(L/R/U/D) |
| Lampentyp | 6S1PWLEDWithout Driver |
| Signalschnittstelle | Parallel RGB (1 ch, 8-bit) + SPI, 40 pins |
| Eingangsspannung | 3.3V (Typ.)(VCC) |
| Anwendung | HHP |
