| Artikelnummer | PD035VX8 |
| Marke | E Ink |
| Größe | 3.5 |
| Anwendung | HHP |
| Auflösung | 480×640 |
| Komposition | LCM |
| Helligkeit | 500 |
| CR | 600:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | CPU/RGB/SPI |
| Panel-Marke | PVI |
| Panel-Modell | PD035VX8 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 3.5 inch |
| Auflösung | 480(RGB)×640 , VGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 53.28×71.04 mm |
| Umriss | 64×85×4.5 mm |
| Oberfläche | Antiglare |
| Helligkeit | 500 cd/m² (Typ.) |
| Kontrastverhältnis | 600:1 (Typ.) |
| Farben anzeigen | 262K (6-bit) |
| Reaktionszeit | 5/20 (Typ.)(Tr/Td) |
| Blickwinkel | 75/75/50/50 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 3S3PWLEDWithout Driver |
| Signalschnittstelle | CPU/RGB/SPI, 61 pins |
| Anwendung | HHP |
