| Artikelnummer | PD035OX4 |
| Marke | E Ink |
| Größe | 3.5 |
| Anwendung | DSC |
| Auflösung | 320×234 |
| Komposition | LCM |
| Helligkeit | 250 |
| CR | 400:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | Parallel/Serial |
| Panel-Marke | PVI |
| Panel-Modell | PD035OX4 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 3.5 inch |
| Auflösung | 320(RGB)×234 |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 71.6×52.65 mm |
| Umriss | 84.03×65.24×3.73 mm |
| Oberfläche | Antiglare |
| Helligkeit | 250 cd/m² (Typ.) |
| Kontrastverhältnis | 400:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit) |
| Reaktionszeit | 15/25 (Typ.)(Tr/Td) |
| Blickwinkel | 60/60/35/45 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 3S2PWLEDWithout Driver |
| Signalschnittstelle | Digital RGB (8/24-bit), CCIR601/656, 60 pins |
| Eingangsspannung | 3.3/3.3/5.0/15/-15V (Typ.)(VCC/VDD1/VDD2/VGH/VEE) |
| Anwendung | DSC |
