| Artikelnummer | PD035QX2 |
| Marke | E Ink |
| Größe | 3.5 |
| Anwendung | DVC |
| Auflösung | 320×240 |
| Komposition | LCM |
| Helligkeit | 500 |
| CR | 500:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | Parallel/Serial |
| Panel-Marke | PVI |
| Panel-Modell | PD035QX2 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 3.5 inch |
| Auflösung | 320(RGB)×240 , QVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 70.08×52.56 mm |
| Umriss | 78.3×64.5×3.8 mm |
| Oberfläche | Antiglare |
| Helligkeit | 500 cd/m² (Typ.) |
| Kontrastverhältnis | 500:1 (Typ.) |
| Farben anzeigen | 262K (6-bit) |
| Reaktionszeit | 15/25 (Typ.)(Tr/Td) |
| Blickwinkel | 75/75/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| Lampentyp | 3S3PWLEDWithout Driver |
| Signalschnittstelle | Digital RGB (8/24-bit) + SPI, CCIR601/656, 50 pins |
| Eingangsspannung | 3.3/3.3V (Typ.)(VDDA/VDD) |
| rohs: | |
