| Artikelnummer | LTP350QV-E06 |
| Marke | Samsung |
| Größe | 3.5 |
| Anwendung | |
| Auflösung | 240×320 |
| Komposition | LCM |
| Helligkeit | 60 |
| CR | 80:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | TTL |
| Panel-Marke | SAMSUNG |
| Panel-Modell | LTP350QV-E06 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 3.5 inch |
| Auflösung | 240(RGB)×320 , QVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 53.64×71.52 mm |
| Umriss | 64.3×87.1×4.85 mm |
| Oberfläche | Hard coating (3H) |
| Helligkeit | 60 cd/m² (Typ.) |
| Kontrastverhältnis | 80:1 (Typ.) |
| Farben anzeigen | 262K (6-bit) |
| Reaktionszeit | 40 (Typ.)(Tr+Td) |
| Blickwinkel | 40/40/25/35 (Typ.)(CR≥10)(L/R/U/D) |
| Lampentyp | WLED |
| Signalschnittstelle | Parallel RGB (1 ch, 6-bit), 60 pins |
| Eingangsspannung | 3.3/5.0V (Typ.)(DVDD/AVDD) |
