| Artikelnummer | PD035QX1 |
| Marke | E Ink |
| Größe | 3.5 |
| Anwendung | PND |
| Auflösung | 240×320 |
| Komposition | LCM |
| Helligkeit | 450 |
| CR | 400:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | CPU/RGB/SPI |
| Panel-Marke | PVI |
| Panel-Modell | PD035QX1 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 3.5 inch |
| Auflösung | 240(RGB)×320 , QVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 53.64×71.52 mm |
| Umriss | 64×85×3.8 mm |
| Oberfläche | Antiglare |
| Helligkeit | 450 cd/m² (Typ.) |
| Kontrastverhältnis | 400:1 (Typ.) |
| Farben anzeigen | 262K (6-bit) |
| Reaktionszeit | 15/25 (Typ.)(Tr/Td) |
| Blickwinkel | 75/75/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| Lampentyp | 3S3PWLEDWithout Driver |
| Signalschnittstelle | CPU/RGB/SPI, 50 pins |
| rohs: | |
| Anwendung | PND |
