| Artikelnummer | A035QN05 V0 |
| Marke | AUO |
| Größe | 3.5 |
| Anwendung | PP |
| Auflösung | 320×240 |
| Komposition | LCM |
| Helligkeit | 250 |
| CR | 300:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | Serial RGB |
| Panel-Marke | AUO |
| Panel-Modell | A035QN05 V0 2 Compatible model |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 3.5 inch |
| Auflösung | 320(RGB)×240 , QVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 70.32×52.74 mm |
| Umriss | 76.9×63.9×4.27 mm |
| Oberfläche | Hard coating |
| Helligkeit | 250 cd/m² (Typ.) |
| Kontrastverhältnis | 300:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit) |
| Reaktionszeit | 10/15 (Typ.)(Tr/Td |
| Blickwinkel | 60/60/50/55 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 6S1PWLEDWithout Driver |
| Signalschnittstelle | Serial RGB (8-bit) + SPI, 50 pins |
| Eingangsspannung | 3.3/3.3V (Typ.)(VDD/VDDIO) |
| Anwendung | PP |
| A035QN01 V4 | AUO | 3.5 | 320×240 |
| A035QN02 VE | AUO | 3.5 | 320×240 |
| A035QN05 V0 | AUO | 3.5 | 320×240 |
| A035QN05 V1 | AUO | 3.5 | 320×240 |
| EL160.80.50 | Lumineq | 3.5 | 160×80 |
| LH350WS1-SH02 | LG Display | 3.5 | 640×960 |
| NL2432DR22-02B | NLT | 3.5 | 240×320 |
| NL2432HC22-41K | NLT | 3.5 | 240×320 |
| PW035XU1 | E Ink | 3.5 | 320×234 |
| TM035KDH05 | Tianma | 3.5 | 320×240 |
| A035QN05 V0 | AUO | 3.5 | 320×240 |
| A035QN05 V1 | AUO | 3.5 | 320×240 |
| LMS350GF03-001 | Samsung | 3.5 | 320×240 |
| LMS350GF08 | Samsung | 3.5 | 320×240 |
