| Artikelnummer | ACX565AKM-7 |
| Marke | SONY |
| Größe | 3.5 |
| Anwendung | MPH |
| Auflösung | 800×480 |
| Komposition | LCM |
| Helligkeit | 275 |
| CR | 500:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | CDP |
| Panel-Marke | SONY |
| Panel-Modell | ACX565AKM-7 |
| Plattentyp | LTPS TFT-LCD , LCM |
| Panelgröße | 3.5 inch |
| Auflösung | 800(RGB)×480 , WVGA |
| Anzeigemodus | VSPEC II, Normally Black, Transflective |
| aktiver Bereich | 76.8×46.08 mm |
| Umriss | 87.9×52.18 mm |
| Oberfläche | |
| Helligkeit | 275 cd/m² (Typ.) |
| Kontrastverhältnis | 500:1 (Typ.)(Transmissive)24:1 (Typ.)(Reflective) |
| Farben anzeigen | 16.7M (8-bit), CIE193170% |
| Reaktionszeit | 12/7 (Typ.)(Tr/Td) |
| Blickwinkel | |
| Frequenz | 60Hz |
| Lampentyp | 3S2PWLEDWithout Driver |
| Signalschnittstelle | CDP (2 Lane) + SPI, 24 pins |
| Eingangsspannung | 1.8/2.75V (Typ.)(VDDI/VDD) |
| Anwendung | MPH |
