| Artikelnummer | C0240QGLG-T |
| Marke | CMEL |
| Größe | 2.4 |
| Anwendung | MPH |
| Auflösung | 240×320 |
| Komposition | OLED |
| Helligkeit | 200 |
| CR | 10000:1 |
| Farben | 65K/262K |
| Hintergrundbeleuchtung | self |
| Schnittstelle | CPU/RGB/SPI |
| Panel-Marke | CMEL |
| Panel-Modell | C0240QGLG-T |
| Plattentyp | AM-OLED , OLED |
| Panelgröße | 2.4 inch |
| Auflösung | 240(RGB)×320 , QVGA |
| aktiver Bereich | 36.72×48.96 mm |
| Umriss | 40.72×57.32 mm |
| Oberfläche | |
| Helligkeit | 200 cd/m² (Typ.) |
| Kontrastverhältnis | 10000 : 1 (Typ.) |
| Farben anzeigen | 65K/262K , CIE193173% |
| Blickwinkel | 85/85/85/85 (Typ.)(CR＞10)(L/R/U/D) |
| Frequenz | 60Hz |
| Treiber-IC | Built-in S6E63D6 |
| Signalschnittstelle | 8/9/16/18-bit 6800/8080 parallel, 6/16/18-bit RGB, SPI, 61 pins |
| Eingangsspannung | 2.8/1.8V (Typ.)(VCI/VDD3) |
| Anwendung | MPH |
