| Artikelnummer | H497TLB01.4 |
| Marke | AUO |
| Größe | 5.0 |
| Anwendung | MPH |
| Auflösung | 720×1280 |
| Komposition | OLED |
| Helligkeit | 275 |
| CR | 10000:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | self |
| Schnittstelle | MIPI |
| Panel-Marke | AUO |
| Panel-Modell | H497TLB01.4 |
| Plattentyp | AM-OLED , OLED |
| Panelgröße | 5.0 inch |
| Auflösung | 720(RGB)×1280 , WXGA |
| aktiver Bereich | 61.92×110.08 mm |
| Umriss | 65.92×118.64 mm |
| Oberfläche | |
| Helligkeit | 275 cd/m² (Typ.) |
| Kontrastverhältnis | 10000 : 1 (Min.) |
| Farben anzeigen | 16.7M (8-bit), CIE1931100% |
| Blickwinkel | 80/80/80/80 (Min.)(CR≥1600)(L/R/U/D) |
| Frequenz | 60Hz |
| Treiber-IC | Built-in RM69052 |
| Signalschnittstelle | MIPI (4 data lanes), 39 pins |
| Eingangsspannung | 1.8/3.1/3.7V (Typ.)(VDDI/VCI/VBAT) |
| Anwendung | MPH |
