| Artikelnummer | DX08D11VM0AAA |
| Marke | KOE |
| Größe | 3.0 |
| Anwendung | MPH |
| Auflösung | 480×800 |
| Komposition | LCM |
| Helligkeit | 400 |
| CR | 400:1 |
| Farben | 262K/16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | TTL |
| Panel-Marke | HITACHI |
| Panel-Modell | DX08D11VM0AAA |
| Plattentyp | LTPS TFT-LCD , LCM |
| Panelgröße | 3.0 inch |
| Auflösung | 480(RGB)×800 , WVGA |
| Anzeigemodus | IPS, Normally Black, Transmissive |
| aktiver Bereich | 38.88×64.8 mm |
| Umriss | 45.6×76.4 mm |
| Oberfläche | |
| Helligkeit | 400 cd/m² (Typ.) |
| Kontrastverhältnis | 400:1 (Typ.) |
| Farben anzeigen | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193171% |
| Reaktionszeit | 35 (Typ.)(Tr+Td) |
| Blickwinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 1S6PWLEDWithout Driver |
| Signalschnittstelle | Parallel RGB (1 ch, 6/8-bit) + SPI, 49 pins |
| Eingangsspannung | 1.8/2.8/2.8V (Typ.)(IOVCC/VCC/VCI) |
| Anwendung | MPH |
