| Artikelnummer | AL2004A |
| Marke | Other |
| Größe | 3.0 |
| Anwendung | |
| Auflösung | 20×4 |
| Komposition | OLED |
| Helligkeit | |
| CR | |
| Farben | Mono(White) |
| Hintergrundbeleuchtung | self |
| Schnittstelle | CPU |
| Panel-Marke | Amson |
| Panel-Modell | AL2004A |
| Plattentyp | PM-OLED , OLED |
| Panelgröße | 3.0 inch |
| Anzeigeformat | 20 characters × 4 lines |
| Schriftarten anzeigen | 5×7 dots + cursor |
| Zeichengröße | 2.97×4.77 mm |
| Charakterhöhe | 3.55×5.35 mm |
| aktiver Bereich | 70.42×20.82 mm |
| Lünettenbereich | 72.42×22.82 mm |
| Umriss | 98×60×9.7 mm |
| Helligkeit | |
| Kontrastverhältnis | |
| Farben anzeigen | Mono(White) |
| Treiber-IC | Built-in KS0066 |
| Signalschnittstelle | 8-bit parallel, 16 pins |
| Eingangsspannung | 3.3V (Typ.) |
